EC Vibro-Champ®

Model : 8161500
$1,399.99MSRP

In a historic collaboration, Fender introduces its first artist signature amplifiers-EC Series amps bearing the name of legendary guitarist Eric Clapton.

Clapton recorded some of his biggest hits with a tweed Champ; a late 1950s practice amp and Fender classic prized by countless pros for its great low-output sound and easy-to-record performance. He still uses one today, and we’ve answered his call for a special model with several distinctive features by introducing the EC Vibro-Champ. Built to Clapton’s own exacting specifications and handmade in the United States, it’s a fascinating variation on the ’57 Champ designed with a ’50s-era output tube bias tremolo (which produced a more throbbing pulse than later Fender tremolo circuits) and a switchable power attenuator (reduces speaker output). It’s a must for Clapton fans and guitarists who want the ultimate in low-power tube performance.

Features include hand-wired all-tube circuitry on eyelet board with premium components; circuit based on late-’50s Fender Champ amp model 5F1 (about 5 watts); tremolo speed control and footswitch jack (footswitch optional); single 8” Weber® Signature speaker with alnico magnet for dynamic, sensitive response; Groove Tubes® 6V6GT output tube, two 12AX7 preamp tubes and 5Y3GT rectifier tube; Schumacher custom transformers; internal speaker disconnect (allows use of external 4-ohm speaker enclosure); finger-joined solid pine enclosure for warm, resonant tone; lacquered tweed covering with vintage-style brown/gold grille cloth and leather strap handle. Deluxe fitted cover included.

General

General

Series:

Artist Signature

Amplifier Type:

Tube

COLOR/MSRP/PART#:

Tweed
$1,399.99
8161500000


Electronics

Electronics

Controls:

Volume, Speed, Output


Weight And Dimensions

Weight And Dimensions

Amplifier Length:

7.8" (19.8 cm)

Amplifier Width:

12.5" (31.8 cm)

Amplifier Height:

13.5" (34.3 cm)

Amplifier Weight:

16.5 lbs (7.5 kg)


Power Rating

Power Rating

Output Power:

5 Watts

Power Handling:

5 watts


Speakers

Speakers

Speaker Description:

8”, Weber® Signature speaker

Speaker:

One - 8" Weber® Special Design with Alnico Magnet

Total Impedance:

4 Ohm


Controls And Connections

Controls And Connections

Inputs:

Three - (1/4", One High Input and Two Low Inputs)


Hardware

Hardware

Amplifier Covering:

Tweed covering and vintage-style brown/gold grille cloth

Cabinet Material:

Finger-Joined Solid Pine

Handle:

Vintage-Style Leather with Nickel Mounting Hardware

Knobs:

Chicken-Head Style Pointer


Tubes

Tubes

Pre Amp Tubes:

2 x 12AX7

Power Tubes:

1 x 6V6

Rectifier:

Tube (1 x 5Y3GT)


Accessories

Accessories

Cover:

Fitted Cover Included


Miscellaneous

Miscellaneous

Other Features:

Hand-wired all-tube circuitry on eyelet board; premium components throughout, Circuit based on late 1950s 5F1 Champ produces about 5 Watts, Tremolo with speed control and footswitch jack (optional footswitch available, P/N 0994049000), 8” Weber® Signature speaker with Alnico magnet for dynamic, sensitive response, Groove Tubes™ 6V6GT output tube, two 12AX7 preamp tubes, and 5Y3GT rectifier tube, Custom transformers by Schumacher, Switchable output power attenuator reduces the speaker’s output if desired, Disconnectable internal speaker allows use of external 8 Ohm speaker enclosure, Finger-joined solid pine cabinet resonates with a warm, woody tone, Genuine lacquered tweed covering with vintage brown/gold grille cloth and leather strap handle, Deluxe fitted cover is included, Hand made in Corona, California, USA.


OVERALL RATING:

4.3 out of 5 Based on 3 reviews

5 Star
(2)
4 Star
(0)
3 Star
(1)
2 Star
(0)
1 Star
(0)
Value
Features
Design
Ease of Use
Sound

You are welcome to praise or criticize the products you have purchased. However, please be specific in your comments as to why you like or dislike a product, so that it’s helpful to others in their decision-making process. All reviews will be monitored, and normally posted within 1-2 business days. Please refrain from including phone numbers, addresses or URLs in your review. Also, we ask that you please do not post promotional content such as advertisements of any kind (including “for sale” ads), links to your music page or music video, or repeated posts that make the same point excessively. Fender reserves the right to reject publication, without notice, of any review due to content, language or other issues.

Note: currently we are only approving reviews written in English.

Title Test

This is a test alert...

How do you rate this item?

Do you own this item? How many Fender products do you own?

Enter a title for your review:

Review this item:

What is your musical ability?

Style of music you play:

A PHP Error was encountered

Severity: Warning

Message: Invalid argument supplied for foreach()

Filename: details/body.php

Line Number: 849

By submitting this review you agree to our Customer Reviews Policies

Thank you for reviewing this item

Your review is in queue for moderation and will be made available soon. Please do not re-submit your review.

Review Title
(0.0)
Unknown on May 20, 2013

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec interdum egestas congue. Quisque pretium suscipit venenatis. Nam mauris lorem, mattis et cursus auctor, sollicitudin id sem. Nulla eros lorem, euismod id scelerisque at, dapibus eu dui. Sed dui eros, rutrum non luctus vel, ultricies vitae diam. Praesent leo neque, feugiat sed lacinia nec, pharetra in purus. Ut non sem lectus, at ultrices enim. Donec eget enim eget enim consectetur semper. Nullam eget ipsum vitae libero ornare cursus.

Unknown owns this item

Unknown owns Fender product(s)

Return to Reviews

Money well spent.

(5.0)
waltah on March 20, 2013
Amateur Blues Rock

I wanted a small amp to play at home, but wanted great quality. I kind of had the Vibro Champ in mind and took it into the demo room for a while. I took my John Mayer Stratocaster with me to test it and was completely blown away. Basically you just crank up the amp to 10 or 12 and control the sound with your guitar's volume control. It goes from a nice clean to a very impressive swampy overdrive. It's more than loud enough in my house when set to half power. Tube bias tremolo sounds absolutely fantastic and will likely make me use it more than I normally would. Workmanship is very impressive being hand wired and hand built with great materials. When I first saw this amp (before playing it) I thought Fender was nuts to be asking a grand for it. After using it I'd actually say it's not overpriced one bit. When i play through this amp it makes me say "wow" all of the time. If you're looking for a small amp for home use, recording or to mic up on stage this could be the one. You certainly won't get metal tones out of this little monster, but blues sounds don't get much better. Classic rock players should also feel right at home without the use of a bunch of pedals. The value of this amp isn't apparent until you fire it up and hit the first note.

waltah owns this item

Was this review helpful? Flag Review
Value
Features
Design
Ease of Use
Sound

Amazing Recording Champ

(5.0)
jtjunker on March 16, 2013
Amateur Blues Classic Rock Folk

I'm very impressed with this amp... both the tone and the craftsmanship of it. I am an owner of a company that manufactures products in the USA, and it means a lot to me to discover a beautifully made product that is created (somewhat) affordably in our country. It is expensive, but it shows in the details and the sound. The wood, the speaker, the wiring, the leather handle, even that Fender went the extra step to use nice-looking copper-colored screws on the front panel is an example of the thought that was put into this amp. The build quality is superb, however the white lettering on the chrome knob plate has seemed to start wearing off rather quickly... especially around the Input jacks.

The tone is unreal. I also own a 1968 silver-face Virbro Champ that I thought was the holy grail for me. This is better, and certainly quieter with less hum which is very nice. If you really boost this amp (I use an Ego-Booster sometimes) it just melts in a good way. It's amazing to finally see a current production model match or exceed the sought-after vintage Champs I've hunted down over the years.

I play two guitars through this thing. An American Deluxe Tele (the S-1 boost turns this amp into a beast), and a Nighthawk with P90's that really brings the guts + growl of this amp to the surface. My favorite part about the amp is that I find no need to have a single pedal between my guitar and it (I record a lot and occasionally mic it). There are so many sounds available just through it's responsiveness, especially with good pickups.

The tremolo sounds wonderfully warm and really hits the sweet spot as far as it's strength. I think it's fine that there is only a speed control for it. I have one slight criticism here: I wish the speed could get slower actually. Just a slightly broadened range in the speed of the tremolo would make it more usable for me.

I'm trying to be subjective here, but really I'm just absolutely thrilled with the tone and build quality of this thing.

jtjunker owns this item

Was this review helpful? Flag Review
Value
Features
Design
Ease of Use
Sound

EC Vibro Champ hits a sour note

(3.0)
leftrightout on February 20, 2013 (updated February 22, 2013)
Amateur Blues Rock Classic Rock Folk

I eagerly awaited the arrival of my EC Vibro Champ and when it arrived I thought wow sounds great, nice tone with the stock tubes, breaks up well and the vibrato was nice and articulate

Then after an hour a horrible crackling static noise occurred in the amp. After hitting a note it would decay quick and the crackling would start. Took it back to be looked at in Australia. After waiting 3 and half weeks they returned the amp supposedly fixed. Well, after an hour it did it again.

This only occurred on input 1. input 2 was fine but hey i paid for a working amp & i want it to work.

Not happy so it went back, and they sent me a new one.

So after another week i have a new amp that has supposedly been tested and works fine ...... Well after an hour, the same issue but worse than the first one. My primary intention for this amp was for a recording amp and it wasn't good enough. I went and got my money back


hope Fender sorts the problem out - a great sounding little amp otherwise
